The Deye SUN-40K-SG01HP3-EU-BM4 hybrid inverter is a modern, next-generation device designed for the most efficient management of energy resources within solar power plants. It combines the functionality of an inverter, a battery charger, and a solar panel charge controller, ensuring a stable and uninterrupted power supply under any conditions. The device supports 40 kW of power with a 230/400 V three-phase architecture, making it equally effective for use in private homes, commercial, and industrial facilities.
Key features include compatibility with high-voltage lithium-ion batteries in the 160–800 V range, a maximum charge and discharge current of 100 A, and support for 4 independent MPPT trackers. This ensures flexibility when designing systems with varying orientations or lighting conditions for solar modules. The inverter features a high efficiency rating, and its innovative technologies guarantee stable performance even under challenging conditions.
The manufacturer has paid special attention to safety and reliability: the device has an IP65 protection rating, allowing it to be installed outdoors while withstanding exposure to dust, moisture, and temperatures ranging from -40 to +60 °C. The inverter supports asymmetric load distribution across phases, the ability to connect up to 10 devices in parallel for power expansion, and integration with diesel generators. Thanks to modern monitoring and communication capabilities (Wi-Fi, GPRS, Bluetooth, RS485, CAN), it easily integrates into smart energy systems and enables remote control.
Technical Specifications
- Rated power: 40 kW
- Battery type: lithium-ion
- Battery voltage range: 160–800 V
- Maximum charging current: 100 A
- Number of battery inputs: 2
- Number of MPPT trackers: 4
- Maximum PV input power: 64,000 W
- Maximum available PV power: 80,000 W
- PV voltage: up to 1,000 V
- Efficiency: 97.6%, MPPT efficiency over 99%
- Protection rating: IP65
- Operating temperatures: from -40 to +60 °C
- Dimensions: 527 × 894 × 294 mm
- Weight: 80 kg
Application features
The device ensures a stable power supply both in grid-connected mode and in standalone mode (UPS mode). It can be used to optimize energy consumption in residential and commercial projects, reduce electricity costs, and increase energy independence. The 100% asymmetric output function allows for independent load balancing on each phase. Thanks to integration with diesel generators, the system operates reliably even in remote locations with unstable power supply. This makes the inverter a versatile solution for a wide range of tasks in the renewable energy sector.
Total Energo LLC offers professional services for the supply, installation, and configuration of equipment for solar power plants. We provide a comprehensive approach: from the selection of inverters and batteries to the integration of systems into existing infrastructure.
