Vertiv Edge — is a single-phase uninterruptible power supply system with a line-interactive or online topology (depending on the model), designed to protect small and medium-sized IT infrastructure. It is often used in telecommunications cabinets, edge data centers (Edge Computing), video surveillance systems, POS terminals, laboratory and medical equipment. To ensure reliable operation and timely detection of component degradation, periodic technical diagnostics are recommended.
What diagnostics include
Inspection / audit
- Visual inspection of the condition of the case, display, indicators, ventilation holes.
- Monitoring of installation (rack/tower), connection of power cables and load.
- Assessment of operating conditions: temperature, ventilation, humidity, presence of dust or dirt.
Electrical tests
- Checking input voltage parameters: stability, frequency, harmonics level (if applicable).
- Output voltage analysis: accuracy, stability when changing load.
- Simulation of power failure to assess switching to batteries and power restoration.
- Operation check AVR systems (if implemented).
Inverter / bypass / charge
- Testing the inverter under real or simulated load.
- Checking the presence and operability of the internal bypass (automatic or fixed).
- Evaluation of the charge mode: current, voltage, behavior when switching to charge / standby.
- Analysis of logs, errors, event history via display or communication port.
Battery (battery system)
- Overview of the status of internal or external battery modules: terminals, housing, indication.
- Measurement of battery voltage at rest and under load.
- Simulation of operation in offline mode to check the duration of discharge and voltage stability.
- Assessment of battery degradation, charge/discharge cycles, efficiency charge.
Cooling
- Checking the operation of the fans: rotation, noise, absence of errors.
- Measuring the temperature of the case and electronics in operating mode.
- Inspection of ventilation ducts, cleanliness of holes, filters (if any).
Communications / monitoring
- Evaluation of the operation of the display, status indicators and menu navigation.
- Testing USB, SNMP, relay outputs, if implemented.
- Checking integration with Vertiv Power Assist / Power Insight or other BMS systems.
Technical report
- Report with measured parameters (voltage, load, charge, temperature, etc.).
- Estimation of the remaining battery life, operation of the inverter and charging circuit.
- Recommendations for component replacement or further maintenance.
When diagnostics are needed
- Every year — according to the manufacturer's recommendations to ensure warranty and stability of operation.
- After alarms, a sharp loss of autonomous time or failures in the operation of the inverter.
- After installation in a new environment or connecting a new load.
- Before replacing the battery pack or updating the software.
Why choose LLC «Total-Energo»
- Great experience with Vertiv single-phase UPSs, including the Edge series.
- Operational diagnostics without stopping the load or disrupting the continuity of power supply.
- Certified engineers and modern measuring equipment.
- Full technical reporting with conclusions and consultations for customer personnel.
